Measuring Volume
Volume measurements build on area geometry and depth assumptions. Use them for quantities such as excavation, concrete, fill, or insulation only after checking the scale and depth basis.
Updated 2026-06-12 · 5 min read
Drawing A-101.pdf
100%FitExport
12.40 m
Volume measurements should be named clearly so reviewers understand the depth assumption.
Create a volume measurement
- 1
Calibrate the page
Set scale before creating the volume markup.
- 2
Choose Measure Volume
Select Measure Volume from the measurement tool group.
- 3
Trace the area
Click around the boundary that represents the plan area.
- 4
Review assumptions
Use Properties or notes to record the depth or basis used for the calculated quantity.
